UL3512 High Temperature Silicone Insulated Wire with 200C Rating and Round Shape for Industrial Applications
Ürün ayrıntıları
| İletken malzeme | Bakır | Yalıtım malzemesi | Lastik |
|---|---|---|---|
| Nominal Voltaj | 600 V | İletken tipi | Mahsur |
| Şekil | Yuvarlak | Maksimum sıcaklık | 200 ° C |
| Min Sıcaklık | -80°C | Şef inşaatı | Kalaylı Tel |
| Yalıtım kalınlığı | 0.78 mm | Çap | 2.51 mm |
| Maksimum şef direnci | 40.1 Ω/km | Birim uzunluğu | 305/1000 m/ft |
| AWG Boyutu | 1AWG-26AWG | Renk Seçenekleri | Tüm Renkler |
| Nominal kalınlık | 0.78 mm | ||
| Vurgulamak | UL3512 Silicone Insulated Wire,200C High Temperature Wire,Round Shape Silicone Rubber Wire |
||
Ürün Açıklaması
UL3512 High Temperature Silicone Wire 1AWG-26AWG Copper Wire Rubber Car Battery Cable for Auto Electric Vehicle
Premium Silicone Rubber Wire Supplier
Supplies Fortune 500 companies, recognized as a top silicone rubber wire supplier in China.
Product Specifications
| Size (AWG) | Construction (No./mm) | Diameter (mm) | Nominal Thickness (mm) | Insulation Diameter (mm) | Max. Conductor Resistance (Ω/KM) | Unit Length (M)/(Ft) |
|---|---|---|---|---|---|---|
| 0.5 | 20/0.18 | 0.95 | 0.78 | 2.51 | 40.1 | 305/1000 |
| 0.75 | 30/0.18 | 1.17 | 2.73 | 26.7 | ||
| 1 | 40/0.18 | 1.3 | 2.86 | 20 | ||
| 1.25 | 50/0.18 | 1.5 | 3.06 | 14.35 | ||
| 1.5 | 30/0.25 | 1.6 | 3.16 | 13.7 | ||
| 2 | 41/0.254 | 1.85 | 3.41 | 8.78 | ||
| 2.5 | 50/0.25 | 2.06 | 3.62 | 7.16 | ||
| 3 | 60/0.25 | 2.3 | 3.86 | 6.5 | ||
| 4 | 56/0.30 | 2.62 | 4.18 | 4.7 |
Product Images
Company Information
Our Global Clients
Industry Exhibitions
Quality Certifications
Frequently Asked Questions
1. Who Are We?
We are a professional manufacturer of high-temperature wires and cables with 26 years of electric wire experience. Our headquarter is located in Shenzhen, Guangdong, China, and our two production bases are located in Dongguan, Guangdong, China and Jingzhou, Hubei, China.
2. What Can We Provide?
We provide high-temperature wires and cables, silicone tubing - including silicone rubber wire, XLPE, FEP/PFA/ETFE/PTFE wire, new energy cable, and wiring harnesses.
3. Why Choose Us?
- Free samples available
- Competitive pricing
- High quality standards
- Customized service options
4. What Certifications Do We Have?
We hold UL, cUL, VDE, Reach, CE, ROHS, CCC, and CQC certifications.
5. What Services Can We Provide?
Accepted Delivery Terms: FOB, CIF, EXW, FAS, CIP, FCA, DDP, DDU. Accepted Payment Currency: USD, EUR, CNY. Accepted Payment Type: T/T, L/C, PayPal, Western Union, Cash.
